ESD Balancer

TYPE 8235

Load range: 15 – 55 kg   |   Cable travel: 2000 mm

  • ESD protected product design
  • A longer cable is available upon request
  • Freely rotating and swivelling screw-type spring hook for suspension
  • Housing and housing cover of chill-cast aluminum
  • Cable drum of high-strength chill-cast aluminum
  • Ball bearing embedded
  • High-strength special suspension spring
  • Flexible stainless steel cable
  • Adjustable cable stop buffer
  • Screw-type spring hook for load suspension
  • Infinitely variable load setting via endless screw
  • Available without (Type 7235) or with (Type 7236) ratchet lock
  • A longer cable is available upon request

  • ESD protection product design
  • Conductive materials
  • Integrated ground connection against static charge
  • Closed unit
  • Rigid, impact-resistant design
  • Suspension via screw-type spring hook (freely rotating and swivelling design)
  • Includes safety chain as fall protection
  • Integrated mechanism for locking the cable drum
  • High-strength special suspension spring
  • Spring fracture safeguard is standard
  • Screw-type spring hook for load suspension
  • 100% Quality controls by KROMER

ESD Balancer
Product details
ID-no. GTIN Load rangein kg Cable travelin mm Own weightin kg InquirePrices/Details
8235040001 4262466530491 15,0 - 25,0 2000 7,80
8235040002 4262466530507 25,0 - 35,0 2000 8,90
8235040003 4262466530514 35,0 - 45,0 2000 9,50
8235040004 4262466530521 45,0 - 55,0 2000 9,75
