ATEX Balancer
TYPE 8235
Load range: 15 – 55 kg | Cable travel: 2000 mm
- Freely rotating and swiveling screw carabiner hook for suspension
- Housing and cover made of die-cast aluminum
- Cable drum made of high-strength die-cast aluminum
- Sealed ball bearing
- Integrated locking mechanism for the cable drum
- High-quality spring
- High-tensile steel cable
- Quick cable replacement
- Continuously adjustable cable retraction limiter
- Screw carabiner hook for attaching the load
- Continuously adjustable load capacity via adjustment screw
- Quality made in Germany
- Cable extension: Extended cable available on request
- ATEX Protection Zone for Gas: II 2G Ex h IIB T6 Gb X
- ATEX Protection Zone for Dust: II 2D Ex h IIIC T85°C Db X
- Integrated grounding connection to prevent static charging
- Shape- and impact-resistant design made from conductive materials
- Includes safety chain for fall protection
- Encapsulated spring assembly
- Spring breakage protection made of stainless steel
- Load attachment via safety screw carabiner
- 100% quality control by Kromer
Product details
| Item |
GTIN |
Load rangein kg |
Cable travelin mm |
Own weightin kg |
InquiryPrices/Details |
| 8235030001 |
4262466530415 |
15 - 25 |
2000 |
2,9 |
|
| 8235030002 |
4262466530439 |
25 - 35 |
2000 |
3,1 |
|
| 8235030003 |
4262466530453 |
35 - 45 |
2000 |
3,2 |
|
| 8235030004 |
4262466530477 |
45 - 55 |
2000 |
3,4 |
|
