Rust-free Balancer
TYPE 8241
Load range: 12.0 - 100.0 kg | Cable travel: 2000 mm
- Cable travel: A longer cable is available upon request
- Rust-free materials
- Integrated drain hole against waterlogging
- Food grade grease (NSF-conform)
- Freely rotating and swivelling safety hook for suspension, adjustable
- Housing and housing cover of high-strength pressure-cast aluminum
- Cable drum of high-strength pressure-cast aluminum
- Closed ball bearings on both sides
- High-strength, encapsulated special suspension spring
- Flexible stainless steel cable
- Adjustable cable stop buffer
- Screw-type spring hook for load suspension
- Infinitely variable load setting via endless screw
- Patented freewheel protects against overrotation when the spring is released
- Closed unit
- Rigid, impact-resistant design
- Suspension via safety hook (freely rotating and swivelling design)
- Includes safety expansion chain as fall protection
- Integrated mechanism for locking the cable drum
- High-strength, encapsulated special suspension spring
- Patented freewheel protects against overrotation when the spring is released
- Spring fracture safeguard is standard
- Cable overload protection via cable extension limit stop
- Includes ferrule for securing the cable end
- Screw-type spring hook for load suspension
| Item
| GTIN
| Load rangein kg |
Cable travelin mm |
Own weightin kg |
InquiryPrices/Details |
| 8241010001 |
4262466531160 |
12,0 - 20,0 |
2000 |
14,9 |
|
| 8241010002 |
4262466531177 |
20,0 - 30,0 |
2000 |
15,5 |
|
| 8241010003 |
4262466531184 |
30,0 - 45,0 |
2000 |
16,5 |
|
| 8241010004 |
426246653119 |
45,0 - 60,0 |
2000 |
17,3 |
|
| 8241010005 |
4262466531207 |
60,0 - 75,0 |
2000 |
18,9 |
|
| 8241010006 |
4262466531214 |
75,0 - 90,0 |
2000 |
19,3 |
|
| 8241010007 |
4262466531221 |
90,0 - 100,0 |
2000 |
20,2 |
|
