Spring balancers
TYPE 7221 and 7222
Load range: 2.0-14.0 kg | Cable travel: 3.0 m
- Cable travel: A longer cable is available upon request
- Safe suspension with freely rotating and swivelling screw-type spring hook
- Housing of very impact-resistant and abrasion-resistant plastic
- Cable drum of abrasion-resistant plastic
- High-strength special suspension spring
- High-strength steel cable
- Infinitely adjustable cable stop buffer
- Cable wedge allows infinite adjustment of cable length
- Screw-type spring hook for load suspension
- Infinitely variable load setting
- Available without (Type 7221) or with (Type 7222) ratchet lock
- Closed unit
- Rigid, impact-resistant design
- Electrically insulated suspension via screw-type spring hook (freely rotating and swivelling design)
- Includes safety chain as fall protection
- Mechanism for locking the cable drum
- High-strength special suspension spring
- Spring fracture safeguard is standard
- Includes ferrule for securing the cable end
- Screw-type spring hook for load suspension
- GS-certified
| ID No.w/o ratchet lock |
GTINw/o ratchet lock |
ID no.with ratchet lock |
GTINwith ratchet lock |
Capacityin kg |
Strokein m |
Own weightw/o ratchet lock in kg |
Own weightwith ratchet lock in kg |
InquiryPrice |
| 7221 0800 01 |
4262403191020 |
7222 0800 01 |
4262403191501 |
2,0 - 5,0 |
3,0 |
3,3 |
3,5 |
|
| 7221 0800 02 |
4262403191051 |
7222 0800 02 |
4262403191532 |
4,0 - 8,0 |
3,0 |
3,7 |
3,8 |
|
| 7221 0800 03 |
4262403191082 |
7222 0800 03 |
4262403191563 |
7,0 - 10,0 |
3,0 |
3,7 |
3,8 |
|
| 7221 0800 04 |
4262403191112 |
7222 0800 04 |
4262403191594 |
10,0 - 14,0 |
3,0 |
3,9 |
4,0 |
|
